M-08 chassiset er Tamiya sitt siste High-performance bakhjulstrekk settet med gode kjøreegenskaper og høy ytelse. Er på en stiv monocque chassis med nedre dekk og øvre rammeseksjoner. Drivhjul benytter full kulelagre, oljefylte CVA støtedempere, oljefylt gir differensial og universell drivaksel. Den kan monteres med en 225mm (M) eller 239mm (L) hjulbase, noe som gjør den kompatibel med endel eksisterende Tamiya M-chassis deler.
Behøves utenom som ikke er inkludert:
2-kanals fjernkontroll og mottaker
7.2V Ni-Mh batteripakke og lader
Styreservo
Fartsregulator
Motor (anbefalt 540 børstemotor)
Fartsregulator
Body som passer til M-05 chasssiet
Lakk/maling til bodyen
Spesifikasjoner:
RC bygggesett
Chassis type: M-08
Skala: 1/10
Terreng: On-road
Drift: 2WD Bakhjulsdrift
Informasjon fra Tamiya:
This TAMIYA high-performance rear-wheel drive R/C chassis assembly kit is constructed around a rigid monocoque with the main frame split into front and rear sections. It offers superior rear high traction drive characteristics and fuss-free maintenance of parts such as the easy-access differential. C.V.A. (Constant Volume Adjustable) oil shock-damped 4-wheel double wishbone suspension features dedicated long arms and steering linkage components for a range of setup options. A silky-smooth drivetrain utilizes full ball bearings, oil-filled gear differential unit and universal drive shafts. It can be assembled with a 210mm (S), 225mm (M) or 239mm (L) wheelbase, making it compatible with appropriately-sized existing Tamiya M-chassis body parts sets.
• 1/10 scale R/C model assembly kit.
• The chassis is split into front (suspension and servo) and rear (motor and battery) sections. It can be assembled into three different wheelbases: S (210mm), M (225mm) or L (239mm).
• Rear-midship motor powers rear wheels via a differential in the Mid-Rear setup.
• Oil-filled differential gear used from the M-07.
• Features proven M-07 Concept designs: suspension arms, uprights, suspension mounts and aluminum parts.
• Includes CVA oil dampers, universal drive shafts, full ball bearings and hi-torque servo saver.
• Comes with new front suspension mounts (0 degrees) and hub carriers (2 degrees) for a total caster angle of 2 degrees.
• Compatible with M-06 Chassis bodies.
